External PCIe x16 Cable (136pin to 136pin)
| General |
| Connector to Connector |
PCI Express*-to-PCI Express* |
| Physical |
| Circuits (Loaded) |
136 |
| Gender |
Male-Male |
| Lock to Mating Part |
Yes |
| Material - Metal |
Zinc Alloy |
| Pitch - Mating Interface |
0.80mm |
| Single Ended |
No |
| Waterproof / Dustproof |
YES |
| Wire Insulation Diameter |
N/A |
| Wire/Cable Type |
Round |
| Electrical |
| Current - Maximum per Contact |
1A |
| Shielded |
Yes |
| Voltage - Maximum |
30V DC |
| Model No. |
Length |
AWG |
Weight |
| CB-00613 |
0.5m (74546-1611) |
28AWG |
468g |
| CB-00613-01 |
1m (74546-1601) |
28AWG |
729g |
| CB-00613-02 |
2m (74546-1602) |
28AWG |
1040g |
| CB-00613-03 |
3m (74546-1603) |
28AWG |
1425g |
| CB-00613-04 |
4m (74546-1604) |
28AWG |
1737g |
| CB-00613-05 |
5m (74546-1605) |
26AWG |
2622g |
| CB-00613-06 |
6m (74546-1606) |
24AWG |
3077g |
| CB-00613-07 |
7m (74546-1607) |
24AWG |
4418g |
|
