Mini-SAS HD (SFF-8643) 8i (two 4i) plug to PCIe x8 Slot Cable w/SATA 15pin Power
Connectors:
Two Mini-SAS HD (SFF-8643) 4i plug
- 85ohm, 36pin (pitch=0.75)
SATA 15pin Power
PCIe x8 slot
| Part No. | LENGTH A (to SFF-8643) | LENGTH B (to Power) |
| P8XF018C70P15 | 70cm | 15cm |
