PCIe Gen 3 External Mini-SAS HD (SFF-8644) 4x plug AOC Cable
- Data Rate Per Lane:
- 12Gb/s for SAS 3.0
- 8Gb/s for PCIe Gen 3
- Cable Jacket Type: Aqua, LSZH, OD: 3.0mm
- Cable Optical Signal: OM3 Multimode
- Link length up to 100m
- Compliant to SFF-8644 standard in mechanical consideration
- Compliant to SFF-8636 common management interface standard
- Support Hot Plug
Connector:
External Mini-SAS HD 4x 36pin (SFF-8644)
Length:
| Part No. | LENGTH | OD |
P3MSHDAOC-A0030E1 |
3M | 3mm |
| P3MSHDAOC-A0070E1 | 7M | 3mm |
P3MSHDAOC-A0100E1 |
10M | 3mm |
| P3MSHDAOC-A0150E1 | 15M | 3mm |
| P3MSHDAOC-A0200E1 | 20M | 3mm |
P3MSHDAOC-A0300E1 |
30M | 3mm |
P3MSHDAOC-A0500E1 |
50M | 3mm |
P3MSHDAOC-A1000E1 |
100M | 3mm |
