• PCIEX16E-Q4SC is integrated by the following two key parts:
  • DIP8X-PCIE16XB21
  • Two DP16S2-51XX2XXA

PCIEX16E-Q4SC is PCIe x16 edge connector to four PCIe x16 (x4 mode) Slots Interconnect Cabling solution.

PCIEX16E-Q4SC is integrated by the following two key parts:

• DIP8X-PCIE16XB21---Internal PCIe (two MCIO 8x) to PCI Express x16 Bifurcation Adapter Card
• Two DP16S2-51XX2XXA---Two PCIe Gen 5 x16 Slot (x4 mode) to MCIO 8x Plug Cable & Mini-Fit 6pin Power Plug Cable

Please be noted that your mainboard needs to have PCIe bifurcation mode support.

• Desktop computer equipped with a PCIe x16 slot

Note: Please be noted that your mainboard needs to have PCIe bifurcation mode support.

• EC-00547-0X
  • 5.25 inch ODD Form Factor Metal Case
