FWB2GOF01 is a FireWire 800 to GOF repeater featuring Texas Instrument's TSB81BA3 and Fiber Optical Transceiver.

FWB2GOF01-MTRJ is with one Agilent HFBR-5912E (MT-RJ) Small Form Factor Fiber Optical Transceiver.

Utilizing an IEEE1394 PHY and optical transceiver, the FWB2GOF01 is capable of sending IEEE1394 signals across a optical fiber cable up to 500 meters in length! FWB2GOF01 needs LC/LC or MT-RJ/MT-RJ optical cable. FWB2GOF01 can also be used as a standard IEEE1394b repeater, extending your signal an additional 4.5 meters. It's easy to setup and there is no configuration necessary, like all IEEE1394 compliant hardware.

• Fully Supports Provisions of IEEE P1394b Revision 1.33+ at 1-Gigabit Signaling Rates
• Fully Supports Provisions of IEEE 1394a.2000 and 1394.1995 Standard for High Performance Serial Bus
• Fully Interoperable With Firewire., i.LINK., and SB1394., Implementation of IEEE Std 1394
• Transfer Rate:
  • 1394b at speeds of 800, 400, 200 and 100 Mbps
  • 1394a at speeds of 400, 200 and 100 Mbps.
• Provides Two Fully Backward Compatible, (1394a.2000 Fully Compliant) Bilingual P1394b Cable Ports.
• One Fiber Optical Port
  • FWB2GOF01-MTRJ is with Multisourced 2 x 5 Package Style with Integral MT-RJ Connector.
• DC Power input Connector: Walkman-type 2.0 mm DC Jack
• Power Input Range: DC 8V~30V, max. 2A
• Power Consumption: 3 Watts.
• Power and Laser indicator LEDs
  • Power LED illuminates when the FWB2GOF01 is powered.
  • Laser LED illuminates after the fiber optic cable connects two powered FWB2GOF01 repeaters.
• With oneMT-RJ Small Form Factor Fiber Optic Transceiver.
• 850nm VCSEL(Vertical Cavity Surface Emitting Laser)
• Maximum link lengths:
  • 220 m Links in 62.5/125 gm MMF 160 MHz*km Cables
  • 275 m Links in 62.5/125 gm MMF 200 MHz*km Cables
  • 500 m Links in 50/125 gm MMF 400 MHz*km Cables
  • 550 m Links in 50/125 gm MMF 500 MHz*km Cables
• IEC 60825-1 Class 1/CDRH
  • Class 1 Laser Eye Safe

• 93(W) x 62.17(D) x 21.46(H)mm

The FWB2GOF01 is ideal for professional audio/video transmission applications such as broadcasting, scientific research, military, industry vision control, medical monitoring systems, etc.

Application 1

Application 2

• FWB2GOF01-MTRJ optical repeater.
• AC to DC power adapter and power code. (optional)
  • Input：100~240 VAC /47~63 Hz
  • Output：+24VDC/2.7A

Note: Optical cable and Firewire cables not included.
